Active Layer Monitoring
Asiga’s pioneering Smart Positioning System (SPS™) achieves precise layer thickness control of each and every layer, ensuring optimal print accuracy and speed.
4K Imaging Resolution
The latest high resolution imaging chipset delivers extraordinary resolution over a large build envelope.
Auto-Calibrating UV LED
Combining the latest generation of high-power ultraviolet solid-state light sources with an integrated radiometer ensures years of consistent printing performance.
385nm LED as standard.
DLP Micromirror Technology
Achieve the highest standard of reliability with the broadest wavelength capability of any imaging technology.
Features
Specs
Build Volume:
192 x 108 x 147mm
7.55 × 4.25 × 5.78 inches
Pixel Size: 50µm
| Software | Asiga Composer software. Lifetime updates included |
| File Inputs | STL, SLC, PLY, STM (Asiga Stomp file format) |
| Network Compatibility | Wifi, Wireless Direct, Ethernet |
| Power Requirements | 100-240VAC / 500Watts |
| System Sizing | 353 x 441 x 555mm | Weight 32.5Kg .. 13.9 x x 17.3 x 21.8 inches | Weight 71.5 Lbs |
| Packed Sizing | 485 × 615 × 799mm | Weight 44 Kg .. 19 × 24.21 × 31.45 inches | Weight 97 Lbs |
| Warranty | 12 months manufacturer’s warranty |
| Technical Support | Unlimited lifetime technical support included |
| Bundle Includes | 3D printer, Composer software, 1kg Asiga material, 2L build tray, Asiga Flash post-curing chamber, calibration toolkit |
