The imes-icore CORiTEC 350i X PRO is imes-icore’s most powerful lab mill, with a 3.0 kW spindle, absolute measuring system and Power Clamp zero-point clamping. imes-icore reports up to 50% faster milling, making it ideal for labs focused on high-volume titanium, CoCr and full-arch work.
Key benefits:
• 3.0 kW spindle for demanding metal work
• imes-icore reports up to 50% faster milling
• Sourcing and support through Nowak
Features
- 5-Axis Simultaneous Machining
- 3.0 kW Spindle up to 60,000 rpm
- Absolute Measuring System on All Axes
- Power Clamp Zero-Point Clamping (4× Clamping Force)
- 20-Fold Exchangeable Tool Magazine
- Integrated Wet & Dry Processing
- 15.6″ Full-HD Touchscreen
Specs
- Axes: 5 simultaneous; A-axis 360°, B-axis 115°
- Processing: Wet and dry; 3.7 L wet tank
- Spindle: 3.0 kW, up to 60,000 rpm; 6 mm shaft
- Tool Changer: 20-fold
- Materials: Zirconia, glass ceramic, lithium disilicate, hybrid ceramic, CoCr, titanium (pre-milled abutments), sintered metal, composite, PEEK, PMMA, wax
- Indications: Telescopic work, abutments, full dentures, bars
- Power: 100–240 V, 50/60 Hz
- Compressed Air: 6.0–9.0 bar at 80 L/min
- Dimensions (W × D × H): 758 × 790 × 857 mm
- Weight: approx. 220 kg (485 lb)
